Low Pressure Steam Generators

Sioux Steam-Flo®

The Sioux Steam-Flo® Low-Pressure industrial steam generator is a perfect source of low-pressure steam for a variety of commercial and industrial applications. This unit can be used in place of a conventional boiler for low-pressure applications. These industrial steam generators produce 370-3,450 lbs. (168-1,564 kg) per hour of saturated steam in minutes. Sioux has manufactured the Steam-Flo® steam generator since 1939. Thousands of these portable steam generators are in operation worldwide, providing years of trouble-free service.

Features

  • The Sioux Steam-Flo® industrial generator provides continuous, unlimited steam.
  • Easy to maintain and built to last.
  • Skid or leg mount units are available for stationary applications.
  • Open or enclosed trailer units for mobile applications.
  • The unit can be outfitted with an optional water tank and generator for completely self-contained operation.
  • Because of its portability, the Steam-Flo® industrial steam generator is excellent for use in overflow production and outlying area.



Contact Us





Steam-Flo® Product Drawings

All-Electric Steam Generator

Sioux's line of all-electric steam generators utilize immersion heating element(s) inside of the vessel to create steam.  Unlike fuel fired models, these units produce no open flame, fumes, or exhaust, making them ideal for indoor applications where venting is not possible or hinders the portability of the unit.

The model SF-3.8E provides 133bs of low-pressure steam per hour and includes two 1" steam outlets. This unit uses one 38 kW heating element and has an operating current of 46 amps when operated on 480V/3Ph/60Hz.  It is perfect for applications such as wine barrel steaming or for customers that only require a small amount of steam for their application.  The stainless steel cover on the unit protects the components of the system.  Four casters make it easily moved to different areas of the customer's operation.

Sioux's All-Electric SF-11E provides 400lbs of low-pressure steam per hour and is heated with (3) 38kW electric heating elements. Electrical requirements are 480V/3PH/60Hz with an operating current of 140 amps.  A 4" NPT steam outlet can be adapted to a single line/hose or split to feed multiple depending on the customer's application.  The unit can be transported with the built in skid forklift pockets.

*Not available for sale into Canada.

SF-3.8E

SF-11E

Certifications & Standards

  • Sioux’s Low NOx Steam-Flo® steam generators meet California’s South Coast Air Quality standards. 2 Models Available - SF-15LN & SF-50LN
  • Third party approved to UL508A and CAN/CSA-C22.2 No. 14-10, ensuring that the entire control panel assembly meets the UL and CSA standards.
  • The vessel is registered with the National Board of Boiler and Pressure Vessel Inspectors, meets requirements of CSD-1 of the ASME Code, and is built to Section IV of the ASME code and is registered throughout Canada with Canadian Registration Numbers (CRN).

Applications

  • Steaming soil, growing media, and growing containers for commercial greenhouses & nurseries
  • Curing precast concrete
  • Heating aggregates in bins or piles
  • Thawing pipes and valves
  • Heating steam jackets
  • Heating rail tank cars for unloading and cleaning

Application Specific Accessories for the Steam-Flo

Steam-Flo FAQ's
Model #fuelvoltsboiler hpinput btu hrsteam output lbs hrCompare
SF-11DDiesel11511427,000380
SF-11GLP / NG11511427,000380
SF-20DDiesel11520791,000690
SF-25GLP / NG115251,010,000860
SF-50DDiesel115502,000,0001,725
SF-50GLP / NG115502,000,0001,725
SF-100DDiesel2301004,000,0003,450
SF-100GLP / NG2301004,000,0003,450
SF-11D-TMDiesel11511427,000380
SF11-DTTMDiesel11511427,000380
SF-20D-TMDiesel11520791,000690
SF-20-DTTMDiesel11520791,000690
SF-20D-ENCDiesel11520791,000690
SF-50D-TMDiesel115502,000,0001,725
SF-50-DTTMDiesel230502,000,0001,725
SF-50D-ENCDiesel230502,000,0001,725
SF-100D-TMDiesel2301004,000,0003,450
SF-100-DTTMDiesel2301004,000,0003,450
SF-100D-ENCDiesel2301004,000,0003,450
SF-15LN Low NOxNatural Gas11515680,000520
SF-50LN Low NOxNatural Gas230502,000,0001,725
SF11-EN/A48011389,000400
SF3.8-EN/A4803.8129,660133
